Pro 9500 Wire Cable
This is the next evolution of the perfect off-road winch. we've refined this winch to perfection. From confidence-inspiring fast line speeds to low amp draw and a best-in-class mechanical brake, this is the top-of-the-line winch without the high price.
This is the next evolution of the perfect off-road winch. we've refined this winch to perfection. From confidence-inspiring fast line speeds to low amp draw and a best-in-class mechanical brake, this is the top-of-the-line winch without the high price.
This is the next evolution of the perfect off-road winch. we've refined this winch to perfection. From confidence-inspiring fast line speeds to low amp draw and a best-in-class mechanical brake, this is the top-of-the-line winch without the high price.
Five things to know about this winch:
It's fast. Sealed 6.0 HP motors deliver a quick but safe 52 FPM line speed at a low 50 Amp draw.
Smart electronics: Anti-high temperature silver pad, 500A Sealed contactor. Only 360A full load current which is the lowest in the industry field. The contactor will never get stuck.
IP68 rated sealing keeps elements out and winch running.
Smart brake: innovative “Double-lock” 100% load-holding brake design provides zero drag on cable in. Located inside the gearbox away from the drum to eliminate heat transfer to the synthetic rope.
Made to last: stainless steel parts, 3 aluminum tie bars for rigidity and 45 degree clocking freespool for tricky mounts.
Size
A=23.86″(606mm)
B=8.54″(217mm)
C=9.84″(250mm)
D=10″(254mm)E=Φ2.48″(63mm)
Specifications
| Rated Line Pull | 9,500lbs (4309kgs) |
| Motor(Series wound): | DC 12V: 6.0hp/4.4kW |
| Gear Box | 2-Stage Planetary/2-Stage Spur Gear |
| Gear Ratio | 171:1 |
| Clutch | Pull & Turn |
| Braking Action | Automatic, in gear box |
| Fairlead | 4-Way Stainless Steel Rollers |
| Wire Rope | 3/8″×85.3′(9.2mm×26m) |
| Drum Size | 2.48″×8.74″(63mm×222mm) |
| Remote | Waterproof Rubber Remote, 12.7' (3.9m) |
| Dimensions | 23.86″×6.77″×9.84″(606mm×172mm×250mm) |
| Mounting Bolt Pattern | 10″×4.5″(254mm×114mm) |
| Weight | 93.6lbs(42.5kg) |
Performance
| Line Pull | No Load | Full Load |
| Line Speed | 52.5 FPM (16 MPM) | 4.3 FPM (1.3 MPM) |
| Motor Current | 50 Amps | 360 Amps |
Size
A=23.86″(606mm)
B=8.54″(217mm)
C=9.84″(250mm)
D=10″(254mm)E=Φ2.48″(63mm)
Downloadable Technical Sheet PDF
