U5000 Trailer Winch Synthetic Rope
Based on the legendary Superwinch S5000, the U5000 brings a unique footprinted winch designed solely for trailering back to the market. A simple lift tab on the top of the winch engages the freespool for easy unrolling of the winch's synthetic rope. The sealed motor provides a quick pull capable of 5,000lbs.
The synthetic rope offers safety advantages as well as simpler handling vs sharp wire cable.
The units protective plastic cover keeps the weather at bay, extending the life of the winch.
Based on the legendary Superwinch S5000, the U5000 brings a unique footprinted winch designed solely for trailering back to the market. A simple lift tab on the top of the winch engages the freespool for easy unrolling of the winch's synthetic rope. The sealed motor provides a quick pull capable of 5,000lbs.
The synthetic rope offers safety advantages as well as simpler handling vs sharp wire cable.
The units protective plastic cover keeps the weather at bay, extending the life of the winch.
Based on the legendary Superwinch S5000, the U5000 brings a unique footprinted winch designed solely for trailering back to the market. A simple lift tab on the top of the winch engages the freespool for easy unrolling of the winch's synthetic rope. The sealed motor provides a quick pull capable of 5,000lbs.
The synthetic rope offers safety advantages as well as simpler handling vs sharp wire cable.
The units protective plastic cover keeps the weather at bay, extending the life of the winch.
Specifications
| Rated Line Pull | 5000lbs (2268 kgs) |
| Motor(Series wound): | 12v DC: 5.6 hp (4.2 kW) |
| Gear Box | 1-Stage Planetary Gear |
| Gear Ratio | 159:1 |
| Clutch | Lift Lever |
| Braking Action | Dynamic and Mechanica |
| Fairlead | Integrated 4-Way Roller |
| Synthetic Rope | 1/4" x 49.8' (6mm x 15.2m) |
| Remote | 30' Handheld |
| Dimensions | 15.1" x7.2" x 5.98" (383 x 183 x 152) |
| Mounting Bolt Pattern | 2-Bolt 3.69" (93.7mm) |
| Weight | 35.9 lbs (16.3kg) |
Performance
| Line Pull | No Load | Full Load |
| Line Speed | 14.7 fpm (4.5 mpm) | 3.3 fpm (1.0 mpm) |
| Motor Current | 30 Amps | 350 Amps |
Download the FENIX technical sheet PDF here.
